| Items |
Supported Capabilities |
| Types of services |
PCB assembly |
| Material Procurement |
| Turnkey box build |
| Supply chain management |
| Project management |
| New products introduction |
| Product development |
| Functional Testing |
| Conformal coating |
| Labeling & Packaging |
| Customized Logistics Per Customer |
| Laser cut framed SMT solder paste stencils |
| Types of Assembly |
THD (Thru-Hole Device) |
| SMT (Surface-Mount Technology) including BGA assembly |
| SMT & THD mixed |
| Cable assembly |
| 2 sided SMT and THD assembly |
| Order quantity |
1 to 100,000 boards |
| Components |
Passives parts, smallest size 0201 |
| Fine pitch to 8 Mils |
| BGA, uBGA,QFN,POP, ,SOP,PLCC and Leadless chips |
| High pin count press fit |
| Connectors and terminals |
| Component Package |
Reels |
| Cut tape |
| Tube and tray |
| Loose parts and bulk |
| Board dimensions |
Smallest size: 0.2" x 0.2" |
| Largest size: 20x25" |
| Board shape |
Rectangular |
| Round |
| Slots and Cut outs |
| Complex and Irregular |
| Board type |
Rigid |
| Flexible PCB |
| Rigid-Flex boards |
| Assembly process |
Leaded process |
| Lead-Free (RoHS) |
| Design file format |
Gerber RS-274X |
| BOM (Bill of Materials) (.xls, .csv, . xlsx) |
| Centroid(Pick-N-Place/XY file) |
| Electrical testing |
AOI (Automated Optical Inspection) |
| Functional testing |
| Oven profile |
Standard |
| Custom |
| Turnaround time |
5 days for only PCB assembly |
| 10-15 days for turnkey PCB assembly |
